Product Details:

Certification: UL
Model Number: 06H

Payment & Shipping Terms:

Minimum Order Quantity: 5000PCS
Price: Negotiable
Packaging Details: Reel,5Kpcs per Reel
Delivery Time: 10 Workdays
Payment Terms: T/T, Western Union
Supply Ability: 2KKPCS Per Month
Get Best Price Contact Now

Detail Information

Name: SMD Fuse Size: 0603
Speed: Slow Blow Rated Voltage: 32V
Current: 1-5A Interrupt Rate: 50 Amperes At 32V DC
High Light:

surface mount resettable fuse

,

surface mount thermal fuse

Product Description

UL248-14 High Inrush Current Withstand 0603 Slow Blow SMD Fuse 32VDC 1A 1.5A 2A 2.5A 3A 4A 5A



UL248-14 High Inrush Current Withstand 0603 Slow Blow SMD Fuse 32VDC 1A 1.5A 2A 2.5A 3A 4A 5A





Main Features



Apart from protective components , we also can provide customzied offer such as we have been producing all kinds of ODM/OEM PCB in different fileds such as LED,Power suppy, etc.



Name SMD Fuse
Advantage High Inrush Current Withstand
Standard UL248-1 UL248-14
Interrupting Rating 50A@32V
Operating Temperature -55~+125C
Material Substrate:ceramic/glass cover
Termination:sliver over-plated with nickel and tin
Element:silver
Speed Time-delay
Solering method Reflow soldering: 260℃, 10s max
UNSPSC 30212009
HS Custom Number 8536101090



UL248-14 High Inrush Current Withstand 0603 Slow Blow SMD Fuse 32VDC 1A 1.5A 2A 2.5A 3A 4A 5A 0





Size (mm)



UL248-14 High Inrush Current Withstand 0603 Slow Blow SMD Fuse 32VDC 1A 1.5A 2A 2.5A 3A 4A 5A 1





Electrical Characteristics



% of Ampere Rating Opening Time
100% 4 hours Min
200% 1 s~60 s
250% 5 s Max





Part Numbering



Catalog Ampere Voltage
Marking
Melting Integral
No. Rating Rating (A2.S)
06H1100D 1A 32V H 0.017
06H1150D 1.5A 32V K 0.060
06H1200D 2A 32V N 0.183
06H1250D 2.5A 32V O 0.240
06H1300D 3A 32V P 0.270
06H1400D 4A 32V S 0.936
06H1500D 5A 32V T 1.865





Description



High inrush current withstanding capability

Compatible with reflow and wave solder

Rugged ceramic and glass construction

Excellent environmental performance

RoHS Compliant ,Lead Free & Halogen Free material





Environmental Data



Life Test: MIL-STD-202, Method 108A

Humidity Bias: MIL-STD-202 , Method 103

Moisture Resistance Test: MIL-STD-202, Method 106G

Thermal Shock: MIL-STD-202, Method 107G

Terminal Strength Test:AEC-Q200-005 Appendix 2 Note: 1mm (Min)

Vibration: MIL-STD-202, Method 204D

MechanicalShock:MIL-STD-202,Method 213B

Solderability: ANSI/J-STD-002

Resistance to Solder Heat: MIL-STD-202,Method 210A

Resistance to Solvents Test: MIL-STD-202, Method 215A





Application



 Telecommunication: Cell Phones / PDA / DSL

 Computers: LCD Panel / Printers/ Laptop/ Servers

 Consumer Electronics: DVD player / MP3 MP4 Player

 Portable memory  LCD monitors  Disk drives  PDAs  Digital cameras  DVDs

 Cell phones  Rechargeable battery packs  Battery chargers  Set top boxes  Industrial controllers



Time-Current Characteristics



UL248-14 High Inrush Current Withstand 0603 Slow Blow SMD Fuse 32VDC 1A 1.5A 2A 2.5A 3A 4A 5A 2
